Freeze Dryer
冷冻干燥机
Request a Quote
Quote only
冷冻干燥机 / Freeze Dryer
Industries: Pharma, Biology, Food
Request a Quote
This is a high-value instrument — our team will reply with pricing, lead time and shipping.
Specifications
| Model | FD-1A-50 FD-1B-50 FD-1C-50 FD-1D-50 FD-1F-50 |
|---|---|
| Cold Trap Size | ∅240*260mm ∅240*260mm ∅240*260mm ∅240*260mm ∅240*260mm |
| Between | 80mm 80mm 80mm 80mm -- |
| Number of | -- -- 8 pcs -- 8 pcs |
| Vacuum | <5Pa <5Pa <5Pa <5Pa <5Pa |
| Water-Capturin | 3kg/24h 3kg/24h 3kg/24h 3kg/24h 3kg/24h |
| Vacuum Pump | 2L/S 2L/S 2L/S 2L/S 2L/S |
| Power | 900W 900W 900W 900W 900W |
| Main Unit | 36Kg 36Kg 36Kg 36Kg 36Kg |
| Cold Trap | <-80℃ <-80℃ <-80℃ <-80℃ <-80℃ |
| Limit | -90℃ -90℃ -90℃ -90℃ -90℃ |
| Sample Tray | ∅200*4 Layers ∅180*3 Layers ∅200*4 Layers ∅180*3 Layers -- |
Downloads
- Brochure (brochure)
